Main Parameters
Item |
Unit |
GRL-6 |
GRL-10 |
|---|---|---|---|
|
Product rate
|
t/h
|
6-10
|
10-12
|
|
Fitness
|
μm
|
1-5
|
1-5
|
|
Content adjusting range
|
%
|
10%-70%
|
10%-70%
|
|
Content control accuracy
|
%
|
1%
|
1%
|
|
Total power
|
kw
|
31.2
|
40.7
|
|
Overall dimensions (length × width × height)
|
m
|
6.8×2.2×2.53
|
7×2.2×2.53
|
Versatile Production:
This equipment can manufacture emulsified bitumen, SBS modified emulsified bitumen, and more, representing an enhanced version of the RL series.
Adaptive Design:
The soap tanks and pipelines in this equipment are constructed from 304 stainless steel or RPP plastic, adaptable to the production of emulsified bitumen with varying pH levels.
Precision in Action:
The bitumen pump speed is regulated by a frequency converter, ensuring stable operations and precise ratio control.
Revolutionary Measurement:
The newly developed instrument for measuring solid content in emulsified bitumen collects bitumen, soap, and finished product temperatures using 3 sets of temperature sensors. This innovative method does not rely on flow meter solutions and employs a dynamic solid content algorithm for visualizing the finished product's content ratio.
Efficiency Unleashed
Equipped with a high-efficiency heat exchanger, this equipment cools the final emulsified bitumen for improved storage stability. Simultaneously, it heats the cooling water required for emulsified bitumen production. Typically, only the initial water tank requires heating, while subsequent water for production is entirely heated by the heat exchanger.
