Feiteng

RL Series Bitumen Emulsion Machine

RL Series Bitumen Emulsion Machine

Type
  • Product Capacity: 6 t/h ~ 12 t/h
  • Emulsion Fineness: 1μm~5μm

Our Advantages

Our factory, DEZHOU FEITENG ROAD CONSTRUCTION EQUIPMENT CO., LTD., specializes in designing and manufacturing asphalt equipment, mainly including asphalt melting equipment for drum/box/bag packing, asphalt tank, asphalt emulsion equipment and asphalt sprayer, also we have the big advantages as below,

1. Independent design and professional manufacturer.

2. Production capacity over 200 sets per year.

3. All equipments with compact structure, suitable for container load.

4. Select premium steel with high quality.

5. Complete production control with detailed record and video.

6. Our factory had passed ISO system authentication, including ISO9001, ISO 14001, OHSAS18001.

7. We manufacture our standard equipment, also welcome OEM and ODM.

Delivery&Shipping

1. Production time around 5-15 days per set

2. Suitable for 40 HQ container loading

3. Trade terms EXW, FOB, CFR, CIF

Our Service

Our factory, DEZHOU FEITENG ROAD CONSTRUCTION EQUIPMENT CO., LTD., specializes in designing and manufacturing asphalt equipment, you may get as below,

1. Design drawing as your requiremen

2. Equipment solution as your real condition

3. Quality equipment as your order

4. Quick response as your time

5. Fast delivery as your demand

6. Complete warranty as your expect

Quality product, quick response and cost saving.

After Sale Service

1. Warranty one year

2. Online support service and video technical support

3. Free spare parts

4. Field installation, commissioning and training, field maintenance

View full details

Main Parameters

Model Production Rate (t/h) Emulsification Fineness (μm) Content Adjustable Range Content Control Accuracy Total Power (KW) Overall Dimensions (Length x Width x Height)
RL-6 4-6 1-5 10%-70% 1% 34 6x2.2x2.5
RL-10 10-12 1-5 10%-70% 1% 42 6x2.2x2.5

Introduction

  • The bitumen emulsion plant is a special equipment used to produce emulsified bitumen. Its main function is to heat-melt the bitumen and use the action of emulsifier and machinery to make the bitumen evenly dispersed in the state of fine particles in an aqueous solution containing an appropriate amount of emulsifier to form emulsified bitumen.


    The equipment uses liquid bitumen and water as processing objects, and the process flow is as follows:

    1. bitumen variable pumping

    2. Heating of water

    3. Emulsifier blending and variable pumping

    4. Proportion of high-temperature bitumen and emulsified solution

    5. The prepared liquid mixture is broken into small droplets through a colloid mill to produce emulsified bitumen.

    6. Cooling and loading of emulsified bitumen finished products.

    There are three options for heating production water:

    Electric heating, thermal oil heating and oil-fired boiler heating.

    In addition, the "YZSL series fuel double-heated bitumen storage tank" produced by our company and specially designed for emulsified bitumen equipment can be equipped. The high-temperature thermal oil supplied from this tank can heat the production water and preheat the bitumen pipeline.

Main Features

  • ① The equipment is suitable for general emulsified bitumen production.
    ② The equipment supporting the emulsion blending tank is made of 304 stainless steel, 2 blending tanks in turn, to ensure continuous production of emulsified bitumen, to reduce intermittent operations due to the ratio of debugging the chances of scrap.
    ③ To solve the emulsion and bitumen ratio, the use of a flow meter stainless steel multi-polar impeller pump, and an electric speed gear pump, adjust the flow of emulsion and bitumen, and then through the high-speed shear and grinding of the emulsifying machine, the formation of emulsified asphalt.
    ④ The matching bitumen pump is an insulated gear pump, which has the characteristics of stable operation and low noise. The bitumen pump and pipeline are designed with an insulated jacket, which eliminates the trouble of cleaning the pipeline.

Advantages

    FEITENG-Top-Quality-Asphalt-Emulsion-Plants-Bitumen-Equipment

    Versatile Production:

    This equipment can manufacture emulsified bitumen, SBS modified emulsified bitumen, and more, representing an enhanced version of the RL series.

    FEITENG-Stainless-Steel-Tank-RPP-Pipeline-for-pH-Adaptable-Emulsified-Bitumen-Production

    Adaptive Design:

    The soap tanks and pipelines in this equipment are constructed from 304 stainless steel or RPP plastic, adaptable to the production of emulsified bitumen with varying pH levels.

    FEITENG-Frequency-Converter-Controlled-Bitumen-Pump-for-Enhanced-Stability

    Precision in Action:

    The bitumen pump speed is regulated by a frequency converter, ensuring stable operations and precise ratio control.

    FEITENG-emulsified-bitumen-solid-content-tester

    Revolutionary Measurement:

    The newly developed instrument for measuring solid content in emulsified bitumen collects bitumen, soap, and finished product temperatures using 3 sets of temperature sensors. This innovative method does not rely on flow meter solutions and employs a dynamic solid content algorithm for visualizing the finished product's content ratio.

    FEITENG-Heat-Exchanger-Enabled-Stability-in-Emulsified-Bitumen-Equipment

    Efficiency Unleashed

    Equipped with a high-efficiency heat exchanger, this equipment cools the final emulsified bitumen for improved storage stability. Simultaneously, it heats the cooling water required for emulsified bitumen production. Typically, only the initial water tank requires heating, while subsequent water for production is entirely heated by the heat exchanger.

    Bitumen emulsion is widely used in road construction and maintenance:

    1. New road construction: prime coat, adhesive coat and seal coat;
    2. road maintenance: fog seal, slurry seal, micro surfacing treatment, chip seal, ultra thin wearing layer, pothole rehabilitation and etc.;
    3. Road pavement recycling: cold in-place recycling asphalt.


    RL /GRL/QRL seriesdeveloped by FEITENG is an ideal equipment for bitumen emulsion production.

    FAQ

    Q: Are you Factory or trading company ?
    A: We are Factory with 15 years of production experience.

    Q: What's your advantages?
    A: More than 15 years experience, professional design, fast delivery and quick response.

    Q: How's about the payment terms?
    A: We usually accept T/T, LC. T/T: 30% in advance as down payment, the balance before delivery.

    Q: How's about the trade terms?
    A: EXW, FOB, CFR and CIF are acceptable.

    Q: How about the delivery time?
    A: Usually we need about 20 days production time after down pay.

    Q: How about after-sale service?
    A: Our products' quality warranty is one year after delivery, we can provide online support, also can send out our engineers to your place if you want.

    Q: What should I do for the quality problems?
    A: If you meet quality problems please send to me the products photo first ,our after service department will deal with for you.

    Your inquiry will be replied within 24 hours.
