Key Technology & Engineering Advantages
Advanced Intelligent Control
Equipped with a high-end Germany Siemens PLC and an in-cab industrial grade touch screen, the FEITENG 6000L offers unparalleled precision. The application rate is automatically synchronized with the truck speed, ensuring a deviation of less than ±1%.
High-Efficiency Heating System
The integrated thermal oil jacket, combined with a 200,000 kcal/h Italian Riello burner, provides rapid and uniform heating. This design eliminates localized overheating, preserving the chemical properties of the bitumen and ensuring zero coking.
Modular Spraying Technology
Featuring 39 independent intelligent nozzles, the spray bar can be adjusted from 0.2 to 6 meters in width. Each nozzle can be controlled individually, allowing for precise edge treatment and selective spraying in complex road layouts.
Durable Chassis & Construction
Built on the robust Dongfeng 1090 4x2 RHD chassis with a 125HP Cummins engine, this truck is designed for longevity. The tank features a 4mm structural steel shell and a stainless steel jacket, separated by a 40mm high-density rock wool insulation layer.
Technical Specifications
| Item | Specification Details |
|---|---|
| Chassis Model | Dongfeng LC1090 (4x2, RHD) |
| Engine Power | Dongfeng Cummins B125 33 (125HP) |
| Tank Volume | 6,000 Liters (Heavy-Duty Steel) |
| Spraying Width | 0.2 - 6 Meters (Intelligent Control) |
| Spraying Dosage | 0.2 - 3.0 L/㎡ (Precision Range) |
| Control System | Germany Siemens PLC + Industrial Touch Screen |
| Bitumen Pump | QGB680 High-Pressure Pump (680L/min) |
| Heating System | Italy Riello G20 Burner (200,000 kcal/h) |
| Cleaning Mode | High-Pressure Air + Diesel Flushing |
| Dimensions | 7380 x 2280 x 2650 mm |
Intelligent Control
Germany Siemens PLC System
The heart of our 6000L distributor is the Germany Siemens PLC integrated with a high-sensitivity in-cab touch screen. It automatically synchronizes the bitumen pump speed with the truck velocity, ensuring a precise application rate (±1% accuracy) regardless of road conditions.
Precision Spraying
39 Smart Independent Nozzles
Equipped with 39 sets of intelligent nozzles, each individually controlled via the cabin. The spray bar width is adjustable from 0 to 6 meters, allowing for seamless adaptation to different road widths and selective spraying for complex maintenance tasks.
Thermal Efficiency
Indirect Heating & Riello Burner
Utilizing a 200,000 kcal/h Italian Riello G20 burner and a specialized thermal oil jacket, the system provides rapid, uniform heating up to 180°C. This indirect method protects the chemical integrity of modified bitumen and prevents carbonization.
